Inverters

Choose the inverter and you have chosen most of your battery budget with it. The charge current column below is the reason: it sets how many packs you need before the system can charge at full rate. 40 units, each checked against the batteries people actually put next to them.

Model	Continuous	Voltage window	Charge current	Comms	Source
EG4 6000XP	6,000 W	40 to 60 V	120 A	CAN, RS485	Read from datasheet
EG4 18KPV	12,000 W	40 to 60 V	250 A	CAN, RS485	Provisional figure
EG4 FlexBoss21	12,000 W	40 to 60 V	250 A	CAN, RS485	Provisional figure
Sol-Ark 12K	9,000 W	42 to 63 V	175 A	CAN, RS485	Provisional figure
Sol-Ark 15K	12,000 W	42 to 63 V	275 A	CAN, RS485	Provisional figure
Victron MultiPlus-II 48/5000	4,000 W	38 to 66 V	70 A	VE.Bus, CAN	Read from datasheet
Victron Quattro 48/10000	8,000 W	38 to 66 V	140 A	VE.Bus, CAN	Provisional figure
Growatt SPF 5000 ES	5,000 W	40 to 60 V	100 A	RS485	Provisional figure
Growatt SPF 6000T DVM	6,000 W	40 to 60 V	120 A	RS485, CAN	Provisional figure
Deye SUN-12K-SG04LP3-US	12,000 W	40 to 60 V	240 A	CAN, RS485	Provisional figure
Schneider XW Pro 6848	6,800 W	44 to 64 V	140 A	CAN, Modbus	Provisional figure
MPP Solar LV6548	6,500 W	40 to 60 V	120 A	RS485, CAN	Provisional figure
LuxPower LXP-LB-US 12K	12,000 W	40 to 60 V	250 A	CAN, RS485	Provisional figure
OutBack Radian GS8048A	8,000 W	40 to 64 V	130 A	Modbus	Provisional figure
EG4 12000XP	12,000 W	40 to 60 V	250 A	CAN, RS485	Provisional figure
EG4 3000EHV-48	3,000 W	40 to 60 V	80 A	RS485	Provisional figure
Sol-Ark 5K	5,000 W	42 to 63 V	120 A	CAN, RS485	Provisional figure
Sol-Ark 8K	8,000 W	42 to 63 V	165 A	CAN, RS485	Provisional figure
Sol-Ark 30K-3P	30,000 W	150 to 950 V	100 A	CAN, RS485	Provisional figure
Victron MultiPlus-II 48/3000	2,400 W	38 to 66 V	35 A	VE.Bus, CAN	Provisional figure
Victron MultiPlus-II 48/8000	6,400 W	38 to 66 V	110 A	VE.Bus, CAN	Provisional figure
Victron Quattro 48/5000	4,000 W	38 to 66 V	70 A	VE.Bus, CAN	Provisional figure
Victron Quattro 48/15000	12,000 W	38 to 66 V	200 A	VE.Bus, CAN	Provisional figure
Deye SUN-5K-SG04LP1	5,000 W	40 to 60 V	120 A	CAN, RS485	Provisional figure
Deye SUN-8K-SG04LP1	8,000 W	40 to 60 V	190 A	CAN, RS485	Provisional figure
Deye SUN-6K-SG03LP1	6,000 W	40 to 60 V	140 A	CAN, RS485	Provisional figure
Sunsynk 5kW Hybrid	5,000 W	40 to 60 V	120 A	CAN, RS485	Provisional figure
Sunsynk 8kW Hybrid	8,000 W	40 to 60 V	190 A	CAN, RS485	Provisional figure
Growatt SPF 3000TL LVM-48P	3,000 W	40 to 60 V	80 A	RS485	Provisional figure
Growatt SPF 12000T DVM	12,000 W	40 to 60 V	250 A	RS485, CAN	Provisional figure
MPP Solar PIP-5048MK	5,000 W	40 to 60 V	100 A	RS485, CAN	Provisional figure
MPP Solar LV2424	2,400 W	20 to 32 V	80 A	RS485	Provisional figure
LuxPower SNA5000	5,000 W	40 to 60 V	120 A	CAN, RS485	Provisional figure
LuxPower LXP 5K Hybrid	5,000 W	40 to 60 V	110 A	CAN, RS485	Provisional figure
Solis S6-EH1P6K-L	6,000 W	40 to 60 V	125 A	CAN, RS485	Provisional figure
GoodWe ES G2 5048	5,000 W	40 to 60 V	100 A	CAN, RS485	Provisional figure
Schneider Conext SW 4048	3,400 W	44 to 64 V	105 A	Modbus	Provisional figure
Renogy REGO 48V 3500W	3,500 W	40 to 60 V	100 A	CAN, RS485	Provisional figure
OutBack VFXR3648A	3,600 W	40 to 64 V	85 A	Modbus	Provisional figure
Signature Solar 6500EX-48	6,500 W	40 to 60 V	120 A	RS485	Provisional figure

Shopping for an inverter

Listings for the units above. Charge current is the figure to check against your bank before you buy.
